10kv/20kv SPD Encapsulated

Surge Protection Devices

10kV / 20kV SPD Encapsulated

Vitalis Power Engineering Pvt. Ltd. offers highly durable and reliable 10kV and 20kV Encapsulated Surge Protection Devices (SPD) engineered to safeguard sensitive electronic equipment from voltage spikes and transients caused by lightning strikes, grid switching, or power surges. These devices are built using advanced encapsulation technology, ensuring long service life, moisture resistance, and high performance in harsh environments.

Product Overview

The encapsulated SPD modules are designed to suppress overvoltages in AC and DC power lines and provide protection for LED drivers, telecom systems, solar PV equipment, industrial controls, and automation systems. With a fast response time and high energy handling capacity, these surge protectors are an essential component for any modern electrical infrastructure.

Key Features

Rated Surge Capacity: 10kV / 20kV

Encapsulation: Fully sealed, weatherproof resin body

Response Time: 25 ns

Clamping Voltage: ≤ 700V (varies by model)

Maximum Discharge Current (Imax): Up to 10kA / 20kA

Leakage Current: 1µA

Protection Modes: L–N, L–G, N–G (configurable)

Operating Temperature: -40°C to +85°C

Certifications: RoHS, CE, BIS (optional)
